Project Description

Item NO.: CYS-S8255  Digital high torque servo

Description : 8.5Kg high torque with micro size for aircraft

Size : 38.3*13.5*31.2MM

Torque :7.0Kg.cm ~ 8.5Kg.cm

Speed : 0.175sec ~ 0.145sec/60 degree

Voltage : 6.0Volts ~7.4Volts

Weight : 38± 1 g

Datasheet Download
Item No.CYS-S8255
Typedigital
Weight38g±1g
Size38.3*13.5*31.2mm
Control System(+)Pulse Width Control 1500usec Neutral
Operating Voltage6.0-7.4V
Operating Temperature Range(-)10 to +50 °
Operating Speed (6.0V)0.175sec/60°
Operating Speed (7.4V)0.145sec/60°
Stall Torque (6.0V)7.0kg.cm
Stall Torque (7.4V)8.5kg.cm
Operating Angle45deg.one side pulse traveling 500 usec
DirectionAnticlockwise/Pulse Traveling 1000~2000usec
Current Drain (6.0V)3mA/100mA
Current Drain (7.4V)3mA/120mA
Stall Current2.5A/3.0A
Dead Band Width2 usec
Motor TypeCoreless
Bearing TypeBall bearing
Horn gear spline25T
Gear TypeMetal
Connector Wire Length250± 5 mm
Wire infoBrown/Black = Negative
Red = Positive
Orange/White = Signal
